FLIR 14° Lens (f =29 mm) with Case
The FLIR 14° Lens (f = 29 mm) with Case is an interchangeable thermal imaging lens designed to expand the capabilities of compatible FLIR handheld thermal cameras. It gives you a narrower, telescopic field of view so you can see heat details at longer distances or on smaller targets that a standard lens might miss.
Key Features
- 14° × 10° Field of View (FOV): Offers a tighter, more focused thermal image ideal for distant subjects or detailed inspection.
- 29 mm Focal Length: Telephoto setup that magnifies thermal scenes compared to the camera’s standard lens.
- Auto-Calibration (AutoCal): Lens identification and calibration happen automatically once attached to the camera — no manual setup needed.
- Durable Carrying Case Included: Comes with a protective case for transport and storage.
Specifications:
Imaging and optical data
Field of view (FOV): 14° × 10°
Minimum focus distance: 1.0 m (3.28 ft.)
Minimum focus distance with MSX: 1.0 m (3.28 ft.)
Focal length: 29 mm (1.41 in.)
Spatial resolution (IFOV): Dependent on the IR resolution of the camera
• 320 × 240 pixels: 0.75 mrad/pixel
• 464 × 348 pixels: 0.52 mrad/pixel
• 640 × 480 pixels: 0.38 mrad/pixel
Lens identification: Yes, AutoCal
F-number: 1.5
Measurement
Accuracy: ±3°C (±5.4°F) or ±3% of reading, for ambient temperature 15–35°C (59–95°F) and object above
Weight 0.140 kg (0.31 lb.)
Size (L × D) 45.4 × 72 mm (1.79 × 2.83 in.)
What's in the Box:
1 x Telephoto Lens
1 x Protective Carrying Case
