Garmin PS-A302B,Panel-Stereo,AM/FM/BT/USB/AUX/LineOut,Bk,Rtl
Garmin PS-A302B is the all-in-one, plug and play, Panel Stereo from Fusion that delivers premium audio quality from a single unit on board. Enjoy superior audio delivery at all volume levels with Fusion Digital Signal Processing (DSP) that is preconfigured to optimize the audio signal for a consistently enjoyable listening experience.
Optimally designed with built-in amplification, stereo source selection, two 3-inch speakers and passive bass radiator, Fusion panel stereo is the future of sound systems on board your leisure boat.
Installation friendly plug and play design boasts of an IP65 rating for protection against dust and water ingress. The surface mounting spacer allows you to install this stereo with a conventional flush mount or premium flat finish or you may choose to simply use the mounting spacer to mount it on surface.
With multiple sources of music to listen from and handy controls via smart devices or Garmin watch, your boat party is all set to rock the expanse of the sea for this weekend.
Specifications:
Dimension: 13.54" x 6.1" x 1.97"
Weight: 2.54lbs
Water rating: IP65 (when properly installed)
Operating temperature: 32° to 122° F (0° to 50° C)
Current (max): 10 A
Networking
BLUETOOTH® wireless range: up to 30 ft
ANT® wireless range: Up to 10 ft
Wireless frequencies/protocols: BLUETOOTH®: 2.4 GHz @ +9 dBm nominal
ANT®: 2.4 GHz @ +9 dBm nominal
Audio Amplifier: Class-D
Electrical Features
Power Input: 10.8 - 16 VDC
Compass-safe distance: 7.6" (229 mm)
Stereo Features
Peak power: 140 watts
Rated power output (2 ohm): 43 watts RMS x 2 @ 14.4 V input < 1% THD
Built-in Digital Signal Processing (DSP): yes (preconfigured)
Fusion-Link™ control: yes (smart device and Garmin watch)
BLUETOOTH® wireless technology: Yes
ANT® wireless technology: Yes
Multi-language interface: Chinese (Mandarin), Dutch, English, French, German, Italian, Japanese, Spanish
Software updates: USB
Warranty: 1year
Supported sources : AM, FM, BLUETOOTH®, USB audio, iPhone®, iPod®, AUX x2, AOA
Connections
Auxiliary inputs (RCA): 2
USB 2.0 ports: 1
AM/FM ports (Motorola antenna connector): 1
Line out: 1 RCA Output (AUX)
What's in the Box:
1 x Fusion Panel-Stereo
1 x Stereo trim
6 x 6-gauge, self-tapping stainless steel screws
1 x Power wiring harness
1 x Documentation
