T300805 IR Lens, f=5mm (80°) with Case

 T300805 IR Lens, f=5mm (80°) with Case

The FLIR 80-degree lens provides an unmatched wide field-of-view, giving you the ability to inspect large targets and in tight spaces. This lens is compatible with FLIR Exx, T5xx, T8xx, Axxx-Series Smart Sensor, Axxx-Series Imaging Streaming, and A500f/A700f Advanced Smart Sensor thermal cameras.

If you are adding this lens to your existing FLIR thermal camera, your camera will need to be shipped to the nearest FLIR service center for calibration.

SPECIFICATIONS:

Imaging & Optical

Field of View (FOV): 80° × 60°
Minimum Focus Distance: 0.15 m (0.49 ft)
Minimum Focus Distance with MSX: 0.5 m (1.64 ft)
Focal Length: 5 mm (0.20 in)
Lens Identification: Yes, AutoCal
F-number: f/1.3

Spatial Resolution (IFOV)
(Dependent on IR resolution of the camera)
• 320 × 240 pixels: 4.56 mrad/pixel
• 464 × 348 pixels: 3.13 mrad/pixel
• 640 × 480 pixels: 2.29 mrad/pixel

Measurement

Accuracy:
±3°C (±5.4°F) or ±3% of reading

Accuracy Conditions:
Ambient temperature 15–35°C (59–95°F)
Object temperature above 0°C (32°F)

Physical

Weight: 0.140 kg (0.31 lb)
Dimensions (L × D): 45.4 × 72 mm (1.79 × 2.83 in)

WHAT'S IN THE BOX:

1 x FLIR 80° IR Thermal Lens (f = 5 mm)
1 x Protective Hard Lens Case
